Our experienced toolmakers and machinists at Woolf Aircraft Products, Inc. are capable of making precision dies and fixtures that produce parts and assemblies to exact customer specifications. The tooling department produces multiple varieties of bending, assembly, and inspection fixtures as well as forming dies. With an inventory of hundreds of bend radius dies, custom shaped tubes can often be bent with no custom tooling required. By combining our extensive list of standard tooling with custom clamps and assembly fixtures, customers receive parts to their exact specifications with a minimal tooling investment.

We specialize in the design and fabrication of custom clamps used to produce close tangent bends in tubing. The ability to produce close tangent bends allows us to fabricate intricate geometries for a variety of different assemblies from engine components to intake manifolds. Tooling is produced on CNC machining centers and verified using advanced CMM equipment to ensure all dimensions and tolerances required to produce a precision part are met.

To economically produce low to medium volume weldments, a modular fixturing table is utilized. Using a modular set-up allows us to produce a range of parts without creating expensive dedicated tooling for each individual part. For higher volume weldments, dedicated tooling ensures precision and repeatability throughout the life of the part. Regardless of volume, our tooling department can create a custom solution for any application. For more information about our custom tooling capability, see the table below, or contact us directly.

CUSTOM TOOLING CAPABILITIES

Tooling Types

Bend Fixtures
Close Tangent Clamps
Assembly Fixtures
Layout & Inspection Fixtures

Forming Dies
Draw Dies
Blanking Dies

Equipment

CNC Machining Centers
Toolmakers Microscope
CMM Equipment

Tooling Materials

Tool Steel
Stainless Steel
Aluminum

Materials (Part Materials)

Steel
Stainless Steel
Aluminum
Inconel
Titanium
Brass

Copper
Copper-Nickel
Alloy 40 (21Cr-6Ni-9Mn Stainless Steel)
Hastelloy

Additional Services

Bending
End Forming
Boring
Brazing
Welding
Machining
Milling

Shearing
Grinding
Mechanical Assembly
Part Marking
Outside Processing
T-Drill Pullout
CNC Machining

Testing & Inspection

CMM
Laser Micrometer
Air Gauging
Borescope Inspection
ASTM E1417 Type 1 – Method A
(Liquid Penetrant)

Hydrostatic Pressure Testing Up To 10,000 lbs.
Leak Testing

  • Air Under Water
  • Nitrogen Under Water
Production Volume

Prototype
Low Volume
High Volume

Lead Time

Quoted on a Job-By-Job Basis

Additional Information

Industry Focus

Aerospace
Aviation
Medical
Military

Transportation
Automotive
Marine

Industry Standards

Mil-Spec
ASTM
AMS
